C1 - vacuum pump install

Modified on Tue, 15 Mar, 2022 at 2:05 PM

Locate the right side panel


Take off the back cover to access the vacuum area


Remove bottom brace by removing 4 bolts (2 on either side of brace)


Locate vacuum tray


Place the tray inside the machine on the rails and tighten down with self-tapping screws (optional) If you choose to.


Thread filter into Blackbox storm vacuum pump canister. Connect black "bell" to Blackbox Storm vacuum pump.


Place Blackbox Storm vacuum pump on vacuum tray. Attach C1 CNC clear vacuum piping to the black ABS tube on Blackbox vacuum pump and tighten with a steel hose clamp.


Connect Blackbox Storm power cable to the yellow power plug coming out of your C1 controller box


Push tray into C1 CNC and put panel back on to cover up the vacuum tray opening
